Satco Products Inc.
Running Man Green Edge Lit Exit Sign; 120-347V; 2HR backup; Single/Dual Face; Universal Surface or (67/530)
$0.00
Call For Price
Description:
Running Man Green Edge Lit Exit Sign; 120-347V; 2HR backup; Single/Dual Face; Universal Surface or Recessed Mounting; Pivoting Panel
Availability:
  • Manufacturer may be Out Of Stock.
Required Components:

Optional Accessory:

Dimensions:
right arrow Height: 10.57"
right arrow Width: 18.23"
Additional Details:
right arrow Finish: Brushed Aluminum
right arrow Category: Lighting Products
right arrow Sub Category: Exit Sign
right arrow Style: Utility
right arrow Bulb Shape: Integrated LED
right arrow Bulb Type: LED
right arrow Dimmable: Non-Dimmable
right arrow Harmonized Codes: 9405.61.6000
right arrow Ship Carton Height: 8.66
right arrow Ship Carton Length: 18.5
right arrow Ship Carton Width: 4.72
right arrow Warranty: 2-Years
right arrow Amps: 0.028-0.009A
right arrow ANSI Base: Integrated
right arrow Battery Chemistry: Ni-Cad
right arrow CA Prop-65: Lead
right arrow Carton Cubic Feet: 0.4376
right arrow Cartons Per Unit: 1
right arrow CCT Selectable: No
right arrow CEC: Non-Compliant - Only for sale in Canada
right arrow CEC Terse: Non-Compliant
right arrow CEC Web Text: Non-Compliant
right arrow Country Of Origin: China
right arrow CRI: 80+
right arrow Depth: 5.35
right arrow Feature 1: Single or Dual Face
right arrow Feature 10: >500 Life Cycles
right arrow Feature 2: Integrated Battery Backup
right arrow Feature 3: Interchangeable Pictograms
right arrow Feature 4: Universal Mounting with Pivoting Pictogram Panel
right arrow Feature 5: Damp Location Rated
right arrow Feature 6: 120-Minute Battery Run Time
right arrow Feature 7: Complies with ICES-005 Class B
right arrow Feature 8: CSA, OSHA, and NFPA Compliant
right arrow Feature 9: Push-to-Test Button
right arrow Finish Family: Metallic
right arrow Has Emergency Battery: Yes
right arrow Indoor Outdoor: Indoor
right arrow IP Rating: IP40
right arrow JA8 Compliant: No
right arrow Lens Finish: Clear
right arrow Lens Material: Acrylic
right arrow Long Description: Keep your building safe and secure with the SATCO NUVO LED 67-530 Running Man Sign. Choose single or dual-face installation and customize the pictogram to fit your needs. The unique pivoting head on this model allows for optimal positioning based on your l
right arrow Material: Aluminum
right arrow Mounting Procedure: Universal
right arrow Operating Frequency: 60Hz
right arrow Operating Temprature: +10C (+50F) to +40C (+104F)
right arrow Order In Multiples Of: 1
right arrow Pack Type: Box
right arrow Power Factor: 0.38
right arrow Quantity In Pack: 1
right arrow R9 Value: 15
right arrow Replaceable Light Source: No
right arrow RoHS Compliant: Yes
right arrow Romance Copy: Keep your building safe and secure with the SATCO NUVO LED Running Man Signs. Choose single or dual-face installation and customize the pictogram to fit your needs. The unique pivoting head on this model allows for optimal positioning based on your locatio
right arrow Safety Listing: CSAus
right arrow SDS class: LED_Fixture
right arrow Short Description: EX SIGN-CAN-EL-AL
right arrow Sloped Ceiling Compatible: No
right arrow Specification Notes: Ni-Cad Battery; 120 minute discharge time
right arrow Temperature (CCT): 5700K
right arrow Title 20 Compliant: No
right arrow Title 24 Compliant: No
right arrow Total Harmonic Distortion: 120%-140%
right arrow Wattage Selectable: No
right arrow Weight Lb.: 5.95
right arrow Standard Option: LED , Prop 65 prop65.png
Vendor Item #:
67/530
