Running Man Green Edge Lit Exit Sign; 120-347V; 2HR backup; Single/Dual Face; Universal Surface or Recessed Mounting; Pivoting Panel

Finish:
Brushed Aluminum

Category:
Lighting Products

Sub Category:
Exit Sign

Style:
Utility

Bulb Shape:
Integrated LED

Bulb Type:
LED

Dimmable:
Non-Dimmable

Harmonized Codes:
9405.61.6000

Ship Carton Height:
8.66

Ship Carton Length:
18.5

Ship Carton Width:
4.72

Warranty:
2-Years

Amps:
0.028-0.009A

ANSI Base:
Integrated

Battery Chemistry:
Ni-Cad

CA Prop-65:
Lead

Carton Cubic Feet:
0.4376

Cartons Per Unit:
1

CCT Selectable:
No

CEC:
Non-Compliant - Only for sale in Canada

CEC Terse:
Non-Compliant

CEC Web Text:
Non-Compliant

Country Of Origin:
China

CRI:
80+

Depth:
5.35

Feature 1:
Single or Dual Face

Feature 10:
>500 Life Cycles

Feature 2:
Integrated Battery Backup

Feature 3:
Interchangeable Pictograms

Feature 4:
Universal Mounting with Pivoting Pictogram Panel

Feature 5:
Damp Location Rated

Feature 6:
120-Minute Battery Run Time

Feature 7:
Complies with ICES-005 Class B

Feature 8:
CSA, OSHA, and NFPA Compliant

Feature 9:
Push-to-Test Button

Finish Family:
Metallic

Has Emergency Battery:
Yes

Indoor Outdoor:
Indoor

IP Rating:
IP40

JA8 Compliant:
No

Lens Finish:
Clear

Lens Material:
Acrylic

Long Description:
Keep your building safe and secure with the SATCO NUVO LED 67-530 Running Man Sign. Choose single or dual-face installation and customize the pictogram to fit your needs. The unique pivoting head on this model allows for optimal positioning based on your l

Material:
Aluminum

Mounting Procedure:
Universal

Operating Frequency:
60Hz

Operating Temprature:
+10C (+50F) to +40C (+104F)

Order In Multiples Of:
1

Pack Type:
Box

Power Factor:
0.38

Quantity In Pack:
1

R9 Value:
15

Replaceable Light Source:
No

RoHS Compliant:
Yes

Romance Copy:
Keep your building safe and secure with the SATCO NUVO LED Running Man Signs. Choose single or dual-face installation and customize the pictogram to fit your needs. The unique pivoting head on this model allows for optimal positioning based on your locatio

Safety Listing:
CSAus

SDS class:
LED_Fixture

Short Description:
EX SIGN-CAN-EL-AL

Sloped Ceiling Compatible:
No

Specification Notes:
Ni-Cad Battery; 120 minute discharge time

Temperature (CCT):
5700K

Title 20 Compliant:
No

Title 24 Compliant:
No

Total Harmonic Distortion:
120%-140%

Wattage Selectable:
No

Weight Lb.:
5.95

Standard Option:
LED
, Prop 65
